Chapter 4 - Installing The ADSL Router

1. . For connections to the Ethernet and DSL

interfaces, please refer to the easy start guide.

2. Connect the AC Power Adapter. the type of network, you may want to put the

Note…

Locate a suitable location for the ADSL Router

Depending upon

ower supply on an uninterruptible supply (UPS).

Only use the power adapter supplied with the ADSL Router. A different adapter may

damage the product.

Figure 1-2 : Wireless Router Connection Diagram

Fig 1-2 shows the Wireless 4-port Router connection diagram.
