Chapter 4 Model 466P – Basic Operation

MODEL 160P STACKER – Quick Reference Guide 11

4.3.6 STACKER ENGAGEMENT BRACKET

The Stacker Engagement Bracket consists of three pins to lock the printer and stacker

together. For further details on engagement procedures, see CHAPTER 3 section 3.3

“ENGAGEMENT PROCEDURE”.

4.3.7 INTERNAL MEDIA GUIDE

The Internal Media guide aligns the media to the left edge of the Model 466P.

CAUTION: THIS GUIDE MUST BE DOWN DURING OPERATION. FAILURE TO DO

SO WILL PRODUCE UNDESIRABLE PRINTING RESULTS AND POSSIBLE MEDIA

JAMS.

4.3.8 MEDIA SUPPLY SHAFT

The Media Supply Shaft provides a location for the Continuous Direct Thermal Media

Roll.

4.3.9 RMG – REMOVABLE MEDIA GUIDE

The Removable Media Guide has been provided to assist in the unlikely event of a

“Paper Jam”. This guide can be removed without tools to clear the media path between

the cutter and print head on the printer.

CAUTION: DO NOT OPERATE THE MODEL 466P WITHOUT THE REMOVABLE

MEDIA GUIDE INSTALLED. FAILURE TO DO SO WILL PRODUCE UNDESIRABLE

PRINTING RESULTS AND POSSIBLE MEDIA JAMS.
